Remote Config public beta


Introduction

OWN3D's Remote Config Service is a very simple key-value store which can be used to store values like strings, numbers, booleans, and objects without the need to create your own backend. In future versions, we will add support for pushing updates to the client when the config changes, allowing you to update your extension without the need to reload it.

WARNING

Do not store sensitive data in the Remote Config! The Remote Config is not encrypted and can be accessed by anyone who interacts with the extension. If you need to store sensitive data, we recommend using the Key-Value Store.

Segments

The Remote Config is divided into three segments: global, developer, and broadcaster. Each segment has its own permissions and can be modified by different parties, but all segments can be accessed by all users who interact with the extension.

Permissions needed to modify segments

  • global: Only the developer can change this segment.
  • developer: Only the developer can change this segment.
  • broadcaster: The broadcaster and developer can change this segment.

Generate a JWT token

To write to the Remote Config, you can either use the Extension SDK or generate a JWT token manually. To generate a JWT token manually, you can use the following code snippet:

const token = jwt.sign({
    exp: Math.floor(Date.now() / 1000) + (60 * 60),
    client_id: 'your_extension_id',
    channel_id: '1', // required when writing to the developer or broadcaster segment
    role: 'external',
    scopes: ['*'],
}, 'your_jwt_secret')

Read from the Remote Config Service

Read using the Extension Helper

To read from the Remote Config, you can use the following code snippet:

import { initializeExtension } from '@own3d/sdk/extension'
import { useRemoteConfig } from '@own3d/sdk/remote-config'

const extension = initializeExtension()

const { getSegments } = useRemoteConfig(extension)

const config = await getSegments()

The config object contains the following properties:

ParameterTypeDescription
globalobjectThe global segment of the Remote Config.
broadcasterobjectThe broadcaster segment of the Remote Config.
developerobjectThe developer segment of the Remote Config.

Read using the Remote Config API

To read from the Remote Config, you can use the following code snippet:

const response = await fetch('https://ext.own3d.pro/v1/remote-configs/segments', {
    method: 'GET',
    headers: {
        'Authorization': 'Bearer <token>',
        'Content-Type': 'application/json',
    },
})

const config = await response.json()

Write to the Remote Config Service

To write to the Remote Config, you can either use the Extension Helper or use the Remote Config API. However, writing to the global or developer segment is only possible using the Remote Config API.

The API only accept objects as values. If you want to store a string, you need to wrap it in an object. Arrays will be stored as objects with numeric keys.

We highly recommend to only write to specific keys of the Remote Config, instead of overwriting the whole segment. This will help to avoid conflicts with other services writing to the Remote Config.

To empty a segment, you can send an empty object.

Write using the Extension Helper

WARNING

Inside the Extension, you can only write to the broadcaster segment of the Remote Config. To write to the global or developer segment, you need to use the Remote Config API.

To write to the Remote Config, you can use the following code snippet:

import { initializeExtension } from '@own3d/sdk/extension'
import { useRemoteConfig } from '@own3d/sdk/remote-config'

const extension = initializeExtension()

const { setSegment } = useRemoteConfig(extension)

await setSegment('broadcaster', {
    foo: 'bar',
})

Write using the Remote Config API

To write to the Remote Config, you can use the following code snippet:

const response = await fetch('https://ext.own3d.pro/v1/remote-configs/segments', {
    method: 'POST',
    headers: {
        'Authorization': 'Bearer <token>',
        'Content-Type': 'application/json',
    },
    body: JSON.stringify({
        broadcaster: { foo: "bar" }
    }),
})

Listen to changes of the Remote Config Service

To listen to Remote Config changes, you can use the following code snippet, but be aware that you will receive config changes from all extensions installed by the content creator:

import { initializeExtension } from '@own3d/sdk/extension'
import { useSocket } from '@own3d/sdk/socket'

const extension = initializeExtension()

const { on } = useSocket(extension)

on('remote-config', (data) => {
    // Only handle changes from your extension
    if (data.extension_id !== 'your_extension_id') return

    console.log('Config changed', data)
})

Parameters

ParameterTypeDescription
segmentsobjectThe segments of the Remote Config that have changed.
extension_idstringThe extension id of the extension that has changed the Remote Config.
channel_idstringThe channel id of the channel where the extension is installed.

Using the Remote Config in Twitch Extension

WARNING

This feature is only available for selected partnered developers.

Write using the Remote Config API (as Twitch Extension)

Prerequisite: To be able to write to the Remote Config as a Twitch Extension, you need to have your Twitch Extension connected with your OWN3D Extension. Furthermore, you MUST use the Extension Configuration Service Capability.

Twitch Extensions, using the Remote Config API requires different headers. To write to the Remote Config as a Twitch Extension, you need to use the X-Twitch-Segment-Version header which must be set to the Developer Writable Channel Segment Version of the extension.

Furthermore, you need to use the Authorization header with the value Twitch <token>. The token is the Twitch JWT token which is provided by the Twitch Extension Helper.

Lastly, you need to use the Client-Id header, which must be set to the Client ID of the OWN3D extension.

To write to the Remote Config as a Twitch Extension, you can use the following code snippet:

const response = await fetch('https://ext.own3d.pro/v1/remote-configs/segments', {
    method: 'POST',
    headers: {
        'X-Twitch-Segment-Version': '1',
        'Client-Id': '1',
        'Authorization': 'Twitch <token>',
        'Content-Type': 'application/json',
    },
    body: JSON.stringify({
        broadcaster: { foo: "bar" }
    }),
})

Get Remote Config changes via Twitch PubSub

When using PubSub, we will send a message to the extension when the Remote Config changes. The message will have the following format:

{
  "event": "remote-config-updated",
  "data": {
    "links": {
      "self": "https://cdn.example.com/remote-configs/..."
    }
  }
}

A sample code snippet to handle this message is as follows:

Twitch.ext.listen('broadcast', async (_, __, message) => {
    const payload = JSON.parse(message as string)
    if (payload.event === 'remote-config-updated') {
        const {data} = await axios.get(payload.data.links.self);

        // handle config changes
    }
})

Get Remote Config changes via Twitch Configuration

When using the Twitch Configuration Service, we will store the remote config in the developer configuration. The developer configuration will have the following format:

{
  "links": {
    "self": "https://cdn.example.com/remote-configs/..."
  }
}

A sample code snippet to handle this message is as follows:

Twitch.ext.configuration.onChanged(async () => {
    if (Twitch.ext.configuration.developer) {
        let payload = JSON.parse(Twitch.ext.configuration.developer.content);
        const {data} = await axios.get(payload.links.self);

        // handle config
    }
})
